Loading... Please wait...| Type |
|---|
| Inverter (with Yamaha's Boost Technology) |
| Maximum AC Output (watts / amperes) |
| 3000 W (3500 W with boost) / 25A |
| Rated AC Output (watts / amperes) - Continuous Use |
| 2800 W / 23.3 A |
| AC Voltage & Frequency (HZ) |
| 120 V / 60 HZ |
| Voltage Regulator |
| Inverter (Pulse Width Modulation) |
| Neutral |
| Floating |
| DC Output (volts / amp) |
| 12V / 8.3A |
| Model |
|---|
| MZ175; 171cc, air-cooled (fan assist), OHV, 2-valve, 4-stroke, single |
| Starting System |
| Electric & manual recoil (with auto decompressor) |
| Ignition |
| Transistor Controlled (TCI) |
| Recommended Fuel |
| 87 octane regular gasoline |
| Engine Oil Capacity |
| 0.6L |
| L x W x H mm (in) |
|---|
| 680 x 445 x 555 (26.8 x 17.5 x 21.9) |
| Dry Weight |
| 69kg (152.1lb) |
| Fuel Tank Capacity (L) |
| 13.0 |
| Operating Hours (@ 1 / 4 load) |
| **20.5 hrs |
| Operating Hours (@ rated load) |
| **8.0 hrs |
| Noise Level (@ 7 metres) |
| **54.5~61 dB |
| Non-Fuse Circuit Breaker System (NFB) |
|---|
| Standard |
| Pilot Lamp (AC output) |
| Standard |
| Warning Lamps (overload / low oil) |
| Standard |
| Smart Throttle / Economy Control |
| Standard |
| Oil Watch Warning System |
| Standard |
| Fuel Level Gauge |
| Standard |
| Noise Block (enclosed engine design) |
| Standard |
| Yamaha's Boost Technology (10 second) |
| Standard |
| Automatic Warm-up |
| Standard |
| Spark Arrestor |
| Standard |
| Transportation Wheel Kit |
|---|
| 4 wheel Standard |
| DC Charging Cable |
| Standard |
| Private Use† |
|---|
| 3-years limited |
| Commercial Use† |
| 3-years limited |
